Avi-on’s Sensor Input Module or SIM, is a multipurpose Avi-on network node that can integrate third party analog sensors as well as Avi-on Direct Connect Sensors into the Avi-on network without being tied to a fixture controller.
The SIM gives third party analog sensors, as well as inputs from building control, fire, security, and other systems a simple and low cost method of triggering lighting actions in an Avi-on network. The SIM is triggered by a contact closure (open or closed momentary). The resulting behavior is programmed in the Avi-on network and is similar to the features available to Direct Connect motion sensors.
The SIM is also Direct Connect compatible, and is an ideal choice to use with Avi-on PIR or Microwave Direct Connect sensors for applications that are remote from a lighting fixture or power pack like stand alone motion or daylight sensor placements.
- Simple low, cost integration of third party sensors on the Avi-on network
- Direct Connect sensor compatible
- 12-24VDC power and contact closure inputs
- Small and compact size accommodates integration into multiple installation configurations
- Optional antenna configurations available for mounting in metal enclosures
Avi-on LTE Remote Bridge Avi-on LTE Remote Bridge
PARTS & ORDERING
|Part Number||Description||Antenna||Input Voltage|
|AVI-SIM-12-24VDC-EA||Sensor Input Module, single channel||UFL-Wire||12 - 24 VDC|
The Avi-on family of products consists of load controllers, sensors, wall stations and connectivity products that work together in one big happy family. Load controllers manage dimming, schedules, scenes, groups/zones and more while the sensors are able to detect motion with all new state-of-the-art features. These products work seamlessly with the Av-ion cloud to provide a robust wireless ecosystem.
